Inclined Conveyor ( Z tyep)
Model: JOY-4-1

Machine Features  :

1、The conveyor is made of 304stainless steel sanitary construction and food grade polypropylene (PP )belt , with good appearance, not easily deformed, bear high and low temperature

2、The machine allows for controlled feeds at one or more locations and can easily interface with various types of feeding devices

3、The conveyors are easy installation and disassembly, the belt can be washed by water directly.


Optional parts :

(1)Frame material : 304stainless steel or mild steel

(2)food grade plastic belt (plain or dimpled)

(3) custom design available


无标题文档

Technical Parameters

Model Number

JOY-4-1

Overall belt width

400mm

Available belt width

300mm

side board height

100mm

Middle baffle height

75mm

Discharge height

3198mm

Infeed height

490mm

Conveying speed 17m-25m/min

Belt Character

food grade plastic  belt

Voltage

3P  380V/ 220V,50Hz/60Hz

Packaging Size and Gross weight :Fumigated wooden case

5700(L)*810(W)*930mm(H)/ 460KG
