S conveyor
Model: JOY-4-2
Machine Features :
1、The conveyor is made of 304stainless steel sanitary construction and food grade polypropylene (PP )belt , with good appearance, not easily deformed, bear high and low temperature
2、The machine allows for controlled feeds at one or more locations and can easily interface with various types of feeding devices
3、The conveyors are easy installation and disassembly, the belt can be washed by water directly.
Optional parts :
(1)Frame material : 304stainless steel
(2)food grade plastic belt (plain or dimpled)
(3) custom design available
|
Technical Parameters |
|
|
Model Number |
JOY-4-2 |
|
Overall belt width |
602mm |
|
Available belt width |
450mm |
|
side board height |
102mm |
|
Middle baffle height |
94mm |
|
Discharge height |
3520mm |
|
Infeed height |
750mm |
| Conveying speed |
20m-30m/min |
|
Belt Character |
food grade plastic belt |
|
Voltage |
3P 380V/ 220V,50Hz/60Hz |
|
Packaging Size and Gross weight ：Fumigated wooden case |
5800（L）*1000(W)*1700mm(H)/720KG |
