Conveyor Equipment
Model: Bucket elevator

Machine Features :

1、The conveyor is made of 304stainless steel sanitary construction and food grade polypropylene (PP) bucket. Automatic stop & start sensor control with filling from hopper or to scale

2、Equiped with multihead weigher and packaging machine , widely used in packaging industry.

3、All parts and buckets with safety and easy removal , machine with automatic chain tighten device and overload protection.


Optional parts :

(1)Frame material : 304stainless steel or mild steel

(2)food  grade plastic bucket

(3) custom design available


无标题文档

Technical Parameters

Model Number

JOY-3-5/6

Bucket Volume

2L/ 4L

Overall height

3896mm

Discharge height

3256mm

Conveying speed

10m-12m/min

Bucket material

food grade plastic bucket

Voltage

3P 380V/ 220V,50Hz/60Hz  0.75KW

Packaging Size and Gross weigh:Fumigated wooden case

2150(L)*1500(W)*1230mm(H)/530KG
